Feature
1. It is suitable for processing all kinds of density board, particle board, wood-based panel, ABS board, PVC board, plexiglass board and solid wood with similar wood structure and hardness.
2. The guide rail of mobile worktable is of chrome plated round bar structure with high positioning accuracy.
3. The mobile worktable is made of high strength extruded aluminum alloy, with high strength and no deformation.
R32 | |||
Dimension of sliding table | 3200*375mm | Main motor | 5.5kw |
Corss cut capacity | 3200mm | Lifting up&down style | Manual/Electric |
Maximum cutting width | 1250mm | Scoring saw blade diameter | 120mm |
Saw blade diameter | 300mm | Speed of scoring saw blade | 7000-8000rmp |
Height of cut | 70mm | Scoring spindle diameter | 20mm |
Speed of main saw spindle | 4500/6000rmp | Scoring motor | 0.75KW |
Main spindle diameter | 30mm | Gross weight | 850kg |
Tilting saw blade | 0-45 degree | Overall dimension | 3250*3350*900mm |
Due to needs of continuous improvement, specifications are subject to change without prior notice.
